Product Details:
|
| Product Name: | Tunnel Mucking Loader | Usage: | Mining Core |
|---|---|---|---|
| Color: | Customer's Request | Advantage: | High Capacity |
| Application: | Mining Equipment | Certificate: | ISO CE |
Coal Mine Drilling Machine
Product Description
-The Coal Mine Drilling Machine is the new multi-function mining machine which is specially engineered for coal mine drilling.
-In order to make sure that the equipment is available to work steadily and consistently with outstanding performance, it adopts the electric power full-hydraulic drive system with simple operation that the worker can easily learn to control the machine.
-Adopting the strong motor which is equipped with the heat dissipation device, it greatly enhances the working speed that it has high working efficiency, which is warmly welcomed by the customers.
-Scientifically designed, it has endurable service life with sturdy construction as well as good treatment that it is waterproof and dust-proof with the resistance to corrosion and oxygen, which is convenient to maintain and clean.
-Processed with strict requirements by our company, the Coal Mine Drilling Machine has guaranteed quality and elegant appearance that it is fashionable and stylish, which is the perfect solution with low cost for the industry.
|
Technical Data |
|
|
Unloading Height(mm) |
1913 |
|
Minimum Loading Height(mm) |
1680 |
|
Unloading Distance(mm) |
2000 |
|
Maximum Rotation Angle(°) |
±50 |
|
Weight(T) |
13 |
|
Dimension(mm) |
6500x2000x2300 |
|
Loading Capacity(m³/hour) |
120 |
|
Min Turning Radius(mm) |
6000 |
|
Climbing Ability(°) |
≤25(hard ground) |
|
Travelling Speed(m/min) |
2-3.8 |
|
Applied Tunnel Gradient(°) |
≤18 |
|
Motor Power(kw) |
45 |
|
Maximum Material By Size(LxWxH) (mm) |
800x780x700 |
|
Ground Clearance(mm) |
270 |
|
Applied Working Section(W*H) (m) |
≥3x3 |
|
Nominal Working Pressure(Mpa) |
20 |
